China 12.38mm 12.76mm 13.14mm 13.52mm energy saving low-e laminated glass suppliers
- solar control low-e glass with PVB or SGP interlayer;
- Thickness 12.38mm 12.76mm 13.14mm 13.52mm etc.
- Size 1830x2440mm, 2140x3300mm, 2140x3660mm, 2250x3300mm, 2250x3660mm, any customized size could be produced;
- Processing could custom cut size, drill holes, cut notches, polished edges, flat and curved, etc.
- Used as window glass,glass curtain wall, skylight glass, roof glass, canopy glass, etc.
- Production time within 15 days after order is confirmed.
6+6mm solar control energy efficiency low-e laminated safety glass
Introduction
Introduction
Low-E glass as an Energy saving glass, been designed for laminated glass unit will be under a greater U-value and poorer thermal insulating capability. Low-E laminated glass can made by one panel of 6mm low iron float glass or 6mm clear float glass and a piece 6mm Low- E glass bonded with PVB or SGP interlayer film. If need more safety, can be choose tempered safety glass, no matter which composition, all of them are low radiation solar control energy efficiency glass
Low E laminated safety glass specifications:
composition:clear float glass(low iron float glass)+PVB/SGP +Low e emissivity glass
clear toughened glass(6mm low iron toughened glass)+PVB/SGP +Low e tempered glass
Thickness: 12.38mm 12.76mm 13.14mm 13.52mm
Processing: cut to size, drilling holes, cutout, tempered, polished edge, curved/hot bent.
Low e laminated glass options:
Clear low-e laminated glass
Low iron low-e laminated glass
Low-e tempered laminated glass
PVB Low-e laminated glass
SGP Low-e laminated glass
clear toughened glass(6mm low iron toughened glass)+PVB/SGP +Low e tempered glass
Thickness: 12.38mm 12.76mm 13.14mm 13.52mm
Processing: cut to size, drilling holes, cutout, tempered, polished edge, curved/hot bent.
Low e laminated glass options:
Clear low-e laminated glass
Low iron low-e laminated glass
Low-e tempered laminated glass
PVB Low-e laminated glass
SGP Low-e laminated glass
How to choose low e laminated glass?
The low-e laminated glass has the advantages of both low-e glass and laminated glass, so it is high security glass and high thermal performance glass, but different composition low-e laminated glass, will have different performance, such as:
• Ultra clear low-e laminated glass VS normal clear low-e laminated glass
If you need more much higher light transparency, then choose Ultra clear low-e laminated glass, could make sure high level of visible light transmittance when reducing solar heat radiation.
• Low-e tempered laminated glass VS low-e float laminated glass
• Low-e tempered laminated glass VS low-e float laminated glass
If your would more safety , then choose low-e toughened laminated glass, its 3-5 times stronger than normal laminated glass , could perfectly resist bending and hitting, and greatly reduce the risk of thermal breakage.
• SGP low-e laminated glass VS PVB low-e laminated glass
• SGP low-e laminated glass VS PVB low-e laminated glass
If you need more stronger safety, the best choose is SGP low-e laminated glass, cause of its five times stronger and up to 100 times stiffer tha, and when broken, the SGP laminated glass is still stand up, but the PVB laminated glass is fell down.
Application
Based on the high performance, the low-e laminated glass is widely used as window glass, glass curtain wall , skylight glass, roof glass, canopy glass, etc.
